Mech Tech Steel Industries specializes in manufacturing Sparkler Filter Presses, also known as Horizontal Plate Pressure Filters. This system is the gold standard for solid-liquid separation where high clarity and 100% recovery of the filtrate are required.

The Sparkler Filter consists of a stack of horizontal filter plates housed within a pressure-tight vertical vessel. This “closed-loop” design prevents any evaporation or leakage, making it the safest and most efficient choice for filtering volatile, hazardous, or high-value liquids.

Stacked Plate Design: Multiple horizontal plates are supported by a central rod, ensuring uniform cake distribution and preventing "scavenging" or cake dropping.
Leak-Proof Operation: The fully enclosed pressure vessel ensures a zero-leakage process, vital for handling solvents, chemicals, and sterile pharmaceuticals.
cGMP Compliance: Manufactured using premium SS 304, 316, or 316L with a mirror-polished finish to meet stringent food and pharmaceutical standards.
Versatile Filter Media: Compatible with a wide variety of filter media, including filter paper, non-woven cloth, and specialized felt, depending on the required micron rating.
Scavenging Plate Option: Includes a specialized bottom scavenging plate to ensure 100% recovery of the liquid, leaving zero wastage in the vessel.

Crystal Clear Filtrate: Ideal for "Polishing Filtration," removing even the finest suspended particles to give the liquid a sparkling clarity.
High Thermal Stability: Can be equipped with a steam or hot-water jacket for filtering liquids that solidify at room temperature, such as waxes or resins.
Easy Cake Removal: The entire plate bundle can be easily lifted out of the vessel for quick cake disposal and thorough cleaning.
Low Maintenance: With no moving parts inside the vessel, the Sparkler Filter Press offers exceptional reliability and a long service life.
Flexible Capacity: By adding or removing plates from the central stack, you can easily adjust the filtration area to suit different batch sizes.

Pharmaceuticals: Filtration of syrups, intravenous fluids, and bulk drugs (APIs).
Chemicals: Clarification of resins, varnishes, lacquers, and specialty chemicals.
Beverages: Polishing of fruit juices, wine, beer, and sugar syrups.
Cosmetics: Filtration of perfumes, lotions, and essential oils.

Filtration Area 0.2 m² to 20 m² (Customizable)
Capacity 100 LPH to 20,000 LPH (Model dependent)
Material of Construction SS 304 / SS 316 / SS 316L
Plate Sizes (Diameter) 8”, 14”, 18”, 24”, 33” (Standard)
Operating Pressure Up to 6 Bar (Standard)
Design Standard cGMP compliant, easy to clean & assemble

Frequently Asked Questions

What is the main advantage of a Sparkler Filter Press?

The biggest advantage is the Horizontal Plate design. Because the plates are horizontal, the filter cake stays stable even if the pump is turned off or if there are pressure fluctuations. This ensures the filtrate remains crystal clear throughout the batch.

How does it differ from a Vertical Pressure Leaf Filter?

While both are pressure filters, the Sparkler Filter is better suited for smaller batches and liquids requiring extremely high clarity (polishing). Pressure Leaf Filters are typically used for much higher solid-loading and larger-scale industrial processing.

Can I recover 100% of my product from the vessel?

Yes. Our Sparkler Filter Presses come with an optional Scavenging Plate. This allows the last bit of liquid at the bottom of the vessel to be filtered, ensuring zero product wastage at the end of the cycle.

Is it easy to clean between different products?

Absolutely. The entire plate assembly can be removed as a single unit. The plates can then be separated, cleaned, and reassembled with new filter media in a matter of minutes.

Which filter media should I use?

It depends on your application. We can help you choose between filter paper (for fine polishing), filter cloth (for higher solid retention), or non-woven pads for specific chemical compatibilities.
